b-Pellucid ATX
Take a peek inside our new cases
b-Pellucid ATX
Middle Tower ATX
b-Pellucid ATX
Accommodate up to 10 Fans for Massive Air Cooling effect and to show off your Gaming Rig with ARGB Fan Lighting Effect.
b-Pellucid MicroATX
Accommodate up to 7 Fans for Massive Air Cooling effect and to show off your Gaming Rig with ARGB Fan Lighting Effect.
FEATURE
- Pellucid Crystal-Clear View with Infinity Tempered Glass Design from Front to Side Panel
- Accommodate up to 10 Fans for Massive Air Cooling effect and to show off your Gaming Rig with ARGB Fan Lighting Effect.
- Slim Mid Tower Design yet Spacious Interior can Accommodate GPU Length up to 420mm, Power Supply up to 200mm Depth,
CPU heatsink up to 185mm tall, and Support 120/240/280/360mm Radiator in various locations. - Built-in USB Type C and USB3.0 Ports.
- Removable and Washable Drawer-like Dust Filter at the Bottom Panel.
- Support 3 x 3.5” HDD or 3 x 2.5” SSD
- Support ATX, MicroATX, and Mini ITX Motherboards.
- Fans are sold separately. Highly recommend b-ARGB DualRing Fan for ultimate ARGB lightning effect.
- Also available in different size: b-Pellucid MicroATX
ATX, Micro ATX and ITX Motherboards
Water Cooling
Fans (Not Included)
Drive Bay and Power Supply
VGA Card
Features
Models / Colors and Accessories
Features
- Pellucid Crystal-Clear View with Infinity Tempered Glass Design from Front to Side Panel
- Accommodate up to 10 Fans for Massive Air Cooling effect and to show off your Gaming Rig with ARGB Fan Lighting Effect.
- Slim Mid Tower Design yet Spacious Interior can Accommodate GPU Length up to 420mm, Power Supply up to 200mm Depth,
CPU heatsink up to 185mm tall, and Support 120/240/280/360mm Radiator in various locations. - Built-in USB Type C and USB3.0 Ports.
- Removable and Washable Drawer-like Dust Filter at the Bottom Panel.
- Support 3 x 3.5” HDD or 3 x 2.5” SSD
- Support ATX, MicroATX, and Mini ITX Motherboards.
- Fans are sold separately. Highly recommend b-ARGB DualRing Fan for ultimate ARGB lightning effect.
- Also available in different size: b-Pellucid MicroATX
Models / Colors and Accessories
- Black
- Fans not included.
| b-Pellucid ATX | |
|---|---|
| UPC Code: | 853704001763 |
| Product Number: | BG01763 |
| Case Type: | Middle Tower ATX |
| Chassis Thickness: | 0.6mm |
| Motherboards: | ATX / Micro-ATX / ITX |
| Dimension (Internal): | 245(W) x 431(D) x 445(H)mm |
| Dimension (Overall): | 245(W) x 434(D) x 473(H)mm |
| Front Panel: | Tempered Glass |
| Side Panel Left: | Tempered Glass |
| Side Panel Right: | Steel |
| Drive Bay HDD (3.5"): | 3 |
| Drive Bay SSD (2.5"): | 3 |
| I/O Port: | USB 3.0 + Type C / MIC / HD Audio |
| Fan Front: | 120mm x 3 (Not Included) |
| Fan Top: | 120mm x 3 or 140mm x 2 (Not Included) |
| Fan Rear: | 120mm x 1 or 140mm x 1 (Not Included) |
| Fan Bottom: | 120mm x 1 or 140mm x 1 (Not Included) |
| PSU Cover: | 120mm x 2 (Not Included) |
| CPU Cooler Height: | Max. 185mm |
| VGA Card Length: | Max. 420mm (If M/B Front is installed with 240/360mm Water Cooling, Max VGA is 280mm) |
| Water Cooling: | Front 120/240/360mm, Top 240/280/360, Rear 120/140mm (All Not Included) |
| Dust Cover: | Bottom Drawer Like Dust Filter |
| Expansion Slots: | 7 |
| PSU Compatibility | PSU length max 200mm (Not Included) |
